LIS2DW12TR

ACCEL 2-16G I2C/SPI 12LGA

Features

• Ultralow power consumption: 50 nA in power-down mode, below 1 µA in active low-power mode

• Very low noise: down to 1.3 mg RMS in low-power mode

• Multiple operating modes with multiple bandwidths

• Android stationary detection, motion detection

• Supply voltage, 1.62 V to 3.6 V

• Independent I/O supply

• ±2g/±4g/±8g/±16g full scale

• High-speed I²C/SPI digital output interface

• Single data conversion on demand

• 16-bit data output

• Embedded temperature sensor

• Self-test

• 32-level FIFO

• 10000 g high shock survivability

• ECOPACK and RoHS compliant

Applications

• Motion detection for wearables

• Gesture recognition and gaming

• Motion-activated functions and user interfaces

• Display orientation

• Tap/double-tap recognition

• Free-fall detection

• Smart power saving for handheld devices

• Hearing aids

• Portable healthcare devices

• Wireless sensor nodes

• Motion-enabled metering devices

Description

The LIS2DW12 is an ultralow-power high-performance 3-axis linear accelerometer belonging to the “femto” family, which leverages on the robust and mature manufacturing processes already used for the production of micromachined accelerometers.

The device has user-selectable full scales of ±2g/±4g/±8g/±16g and can measure accelerations with output data rates from 1.6 Hz to 1600 Hz.

The LIS2DW12 has an integrated 32-level first-in, first-out (FIFO) buffer allowing the user to store data in order to limit intervention by the host processor.

The embedded self-test capability allows the user to check the functioning of the sensor in the final application.

The device has a dedicated internal engine to process motion and acceleration detection including free-fall, wake up, highly configurable single/double-tap recognition, activity/inactivity, stationary/motion detection, portrait/ landscape detection, and 6D/4D orientation.

The LIS2DW12 is available in a small thin plastic, land grid array (LGA) package and it is guaranteed to operate over an extended temperature range from -40°C to +85°C.
